Masterclock, Inc.



phone(USAandCanada):1‐800‐940‐2248|phone(international):+1‐636‐724‐3666

email:[email protected]|online:www.masterclock.com





FEATURES

• Usesexternal(oryourowninternal)NTPsourceforaccurate

timetraceabletoNIST

• ‐11.5to+12hour,TimeZoneoffsetsin30‐minuteincrements

• DaylightSavingstime‐USandCanadastandard(othersoptional)

• UsesstandardEthernetwiring

• Microprocessorcontrolledsteppermotorforreliable,accurate,andquietoperation

• Sweepsecondhand

• UniversalACinputvoltageandfrequency

• OptionalPoE(PoweroverEthernet)

• Internalcrystalandclockchip

• LEDStatusIndicator

• Standardchassiscolorisblack.Othercolorsavailablewithminimumorder.



NTP Analog Clock

CLKNTD 12

SPECIFICATIONS



SetupandControlSoftware

SupportsDHCP/BOOTPforautomaticacquisitionofnetwork

address,nameservers,andtimeserverconfiguration

•NTPsynchronizationoptionsandmore

•Providesdynamicconfigurationfornetworkingparameters,time

zone/daylightsavingtime

•Configureclocksthroughprovidednetworkdiscoverytoolor

TELNET

•Networkdiscoverytoolprovidesautomaticdiscovery

ofNTP

clocksattachedtonetworkwithoutchangingPC’snetwork

configuration

•Configurationissavedtonon‐volatilememoryandsurvivespower

losses

•Encryptednetworkmessagespreventunauthorizedtamperingof

clockconfiguration

OperatingParameters

•Temperature:0to+50°C

•Humidity:Upto90%(non‐condensingat+25°C)

Physical

• 12.5”(31.8cm)roundblackmetalcasewith

polycarbonatelens/crystal,4.25”(10.8cm)high

• Surface/wallmountbracketprovided

• Weight–7.6lbs(3.45kg)

• Optionaltrue24hrfaceavailable

• Optional12/24hrfaceavailable

Power

• 90‐265VAC50/60Hz

• IECACpowerconnectorandcord 

• SpecifyUS,UK,EURO,orAUS/NZplugs

• PoE(PoweroverEthernet)optionavailable

<12.95Wpowerconsumption

Compliance

• CEMarked‐availableforsaleinEU

• FCC,ClassB,Emissions
