Masterclock, Inc.



phone(USAandCanada):1‐800‐940‐2248|phone(international):+1‐636‐724‐3666

email:[email protected]|online:www.masterclock.com



FEATURES

• 14.9”(37.85cm)analogclock

• SMPTE,EBUandIRIG‐B(modulatedandunmodulated)

TimeCodedriven

• Self‐correctingtonon‐dropframeTimeCode

• ‐11.5to+12hour,TimeZoneoffsetsin30‐minuteincrements

• DaylightSavingsTime:USandCanadastandard(othersoptional)

• Microprocessorcontrolledsteppermotorforreliable,accurate,and

quietoperation

• Sweepsecondhand

• UniversalACinputvoltageandfrequency

• FullyconfigurableviaUSBinterfacewithsuppliedCLKSETsoftware

• Standardchassiscolorsavailableareblackorbeige(off‐white)

powdercoat

• Othercolorsavailablewithminimumorder–contactfactoryfor

details



Time Code Analog Clock

CLKTCD 15

SPECIFICATIONS



Inputs

• TimeCodeinputviaBNC

• OptionaltwistedpairtoBNCadapteravailable

forTimeCodeinput:specifyBNC‐pigtail

• TimeZoneoffsetandothersetupswitchesaccessibleon

backpanel



Physical

• 14.9”(37.85cm)roundblackmetalcasewith

polycarbonatelens/crystal,4.25”(10.8cm)high

• Surface/wallmountbracketprovided

• Weight:6.2lbs(2.81kg)

• Optionaltrue24‐hourfaceavailable

• Optional12/24‐hourfaceavailable

Power

• 90‐265VAC50/60Hz

• IECACpowerconnectorandcord

• SpecifyUS,UK,EURO,orAUS/NZplugs

• DCoptionalsoavailable



Compliance

• CEMarked,availableforsaleinEU

• FCC,ClassB,emissions



OperatingParameters

• Temperature:0to+50°C

• Humidity:Upto90%(non‐condensingat+25°C)
